EXEDY Twin Plate Clutch Kit HD for Mitsubishi Evo 4-9 (Cerametallic)

SKU: MM022HD

EXEDY Twin Plate Clutch Kit HD for Mitsubishi Evo 4-9 (Cerametallic)

SKU: MM022HD
Regular price $3,300.00
/
  • Low stock - 3 items left
  • Inventory on the way
 More payment options

The EXEDY Twin Cerametallic Clutch Kit for the Evo 4-9 models is a great clutch if you are both a drag racer and drive your car on the street. The pedal is firm and easy to engage making it one of the most recommended street/race clutches out there! The SD version is good to 450 WHP and the HD is designed to handle more launches and good to 550.

Vehicle Fitment - FITS BOTH 5 AND 6 SPEED:
• 2001-2006 CT9A Evolution 7/8/9
• 1996-2001 CP9A CN9A Evo 4/5/6


Why do I need a twin plate clutch?
Multi plate clutch kits (Twin & Triple Disc) simply put have more than one clutch disc. The stock clutch comes with one disc and by having two or three discs, you essentially double or triple the surface area to be clamped. If you are like most Evo owners, you have probably doubled or tripled your power... so you need to compensate with a more powerful clutch. There will also be intermediate plates between the discs and especially with the Triple kits, when you push in the clutch pedal, you'll hear those plates rattling around free. That's totally normal and fun to mess with your friends.


Features:
• Street, Drag, Road and Rally
• Lightweight Chromoly Steel Flywheel
• Purple Anodized Forged Aluminum Clutch Cover
• Pull-Type Design
• Cerametallic Discs
• SD rated for 450 WHP
• HD rated for 550 WHP

MM022HD Heavy Duty Evo 4-9 Clutch Kit

Notes HD Heavy Duty
Hyper Twin Cerametallic Clutch
Sprung Center Disc
Pull Type Cover
Uses TOB MBAK100
Clamp Load 2652
Disc Diameter (Inches) 7.9
Disc Diameter (Millimeters) 200
Kit Contents CM06H, PP02, IM01, DM13DA, DM13DB, FR01, FM12, BS05, BS01, PR01 and Alignment Tool
Spline Count 23
Spline Size (Inches) 1-1/16
Spline Size (Millimeters) 26.2

Torque Capacity (ft/lbs.)
615



Install Notes:
• Flywheel to Crank Bolt (ft-lb): 99
• Pressure Plate Assembly to Flywheel (ft-lb): 23

The EXEDY Twin Cerametallic Clutch Kit for the Evo 4-9 models is a great clutch if you are both a drag racer and drive your car on the street. The pedal is firm and easy to engage making it one of the most recommended street/race clutches out there! The SD version is good to 450 WHP and the HD is designed to handle more launches and good to 550.

Vehicle Fitment - FITS BOTH 5 AND 6 SPEED:
• 2001-2006 CT9A Evolution 7/8/9
• 1996-2001 CP9A CN9A Evo 4/5/6


Why do I need a twin plate clutch?
Multi plate clutch kits (Twin & Triple Disc) simply put have more than one clutch disc. The stock clutch comes with one disc and by having two or three discs, you essentially double or triple the surface area to be clamped. If you are like most Evo owners, you have probably doubled or tripled your power... so you need to compensate with a more powerful clutch. There will also be intermediate plates between the discs and especially with the Triple kits, when you push in the clutch pedal, you'll hear those plates rattling around free. That's totally normal and fun to mess with your friends.


Features:
• Street, Drag, Road and Rally
• Lightweight Chromoly Steel Flywheel
• Purple Anodized Forged Aluminum Clutch Cover
• Pull-Type Design
• Cerametallic Discs
• SD rated for 450 WHP
• HD rated for 550 WHP

MM022HD Heavy Duty Evo 4-9 Clutch Kit

Notes HD Heavy Duty
Hyper Twin Cerametallic Clutch
Sprung Center Disc
Pull Type Cover
Uses TOB MBAK100
Clamp Load 2652
Disc Diameter (Inches) 7.9
Disc Diameter (Millimeters) 200
Kit Contents CM06H, PP02, IM01, DM13DA, DM13DB, FR01, FM12, BS05, BS01, PR01 and Alignment Tool
Spline Count 23
Spline Size (Inches) 1-1/16
Spline Size (Millimeters) 26.2

Torque Capacity (ft/lbs.)
615



Install Notes:
• Flywheel to Crank Bolt (ft-lb): 99
• Pressure Plate Assembly to Flywheel (ft-lb): 23
